Description

About the Tractel Dynafor LLX1 Load Indicator:



Tractel Dynafor LLX1 Load Indicator series is made up of industrial load indicators with an integrated display. The Dynafor LLX1 dynamometers are precision force sensors which are used to measure forces as well as indicate loads. The shape of the dynamometers enables the use of standard shackles on both ends.

Extreme accuracy as well as full traceability – 0.2% of the maximum measuring range. In addition to the stand-alone application, it is possible to expand the LLX1 series with a separate display. Combined with the remote display, measurements can be easily remotely read.

  • Option to have LLX1 remote reading with range of up to 40m wireless
    • Displays values a variety of units: kg, T, daN kN, lbs
    • Complete with an Integrated 18mm LCD display
    • Equipped with basic functions such as Tare, peak load
    and advanced functions;
    – Adjustable dynamic effects filter.
    – Adjustable automatic shutdown function.
    – Adjustable threshold
    • Requires 3 AA batteries, rechargeable batteries can be used
    • CE compliant: 2006/42/CE
    • CEM compliant: 2004/108/CE
    • Meets IP65, can be used in severe weather conditions
    • Includes built in radio transmitter meaning wireless display can
    be added at a later date if required

Wireless Display:

  • LCD display with backlight
  • 2.4GHz ZigBee
  • Interchangeable displays (16 channels)



Tractel Dynafor LLX1 Load Indicator



Tractel Dynafor LLX1 Load Indicator

View our full catalogue of load cells here
